Name: HIK 8MP 4K COLORVU BULLET 2.8MM DS-2CD2087G2-LU
SKU: 565526

HIK 8MP 4K COLORVU BULLET 2.8MM DS-2CD2087G2-LU

DS-2CD2087G2-LU(2.8mm)(C)

Experience the incredible power of Hikvision ColorVu technology, delivering crystal clear and colorful images 24/7. Through advanced F1.0 lenses, high performance sensors, and friendly lighting, this revolutionary technology captures more light and produces brighter images. With advanced sensor technology, you can maximize the potential of available light and enhance your viewing experience like never before!

FEATURES:

High quality imaging with 8 MP resolution
Efficient H.265 compression technology
Clear imaging against strong back light due to 130 dB WDR technology
Focus on human and vehicle classification based on deep learning
24/7 colorful imaging
Built-in microphone for real-time audio security (-U)

SPECS:

Camera
Image Sensor 1/1.2" Progressive Scan CMOS
Max. Resolution 3840x2160
Min. Illumination Color: 0.0005 Lux @ (F1.0, AGC ON), 0 Lux with Light
Shutter Time1/3 s to 1/100,000 s
Angle Adjustment Pan: 0° to 360°, tilt: 0° to 90°, rotate: 0° to 360°

Lens
Lens Type Fixed focal lens, 2.8, 4, and 6 mm optional
Focal Length & FOV
2.8 mm: horizontal FOV 102°, vertical FOV 52°, diagonal FOV 124°

4 mm: horizontal FOV 88°, vertical FOV 47°, diagonal FOV 104°

6 mm: horizontal FOV 54°, vertical FOV 30°, diagonal FOV 62°
Iris Type Fixed
Aperture F1.0
Depth Of Field
2.8 mm: 4.5 m to ∞

4 mm: 7 m to ∞

6 mm: 13 m to ∞

DORI
DORI
2.8 mm, D: 96 m, O: 38 m, R: 19 m, I: 10 m

4 mm, D: 102 m, O: 41 m, R: 21 m, I: 11 m

6 mm, D: 167 m, O: 66 m, R: 33 m, I: 16 m

Illuminator
Supplement Light Type White light
Supplement Light Range 40m
Smart Supplement Light Yes

Video
MainStream
50 Hz:

25 fps (3840 × 2160, 3200 × 1800 , 2688 × 1520, 1920 × 1080, 1280 × 720)

60 Hz:

24 fps (3840 × 2160)

30 fps (3200 x 1800 , 2688 × 1520, 1920 × 1080, 1280 × 720)
Sub-Stream
50 Hz: 25 fps (640 × 480, 640 × 360)

60 Hz: 30 fps (640 × 480, 640 × 360)
Third Stream
50 Hz: 10 fps (1920 x 1080 , 1280 × 720, 640 × 480, 640 × 360)

60 Hz: 10 fps (1920 x 1080 , 1280 × 720, 640 × 480, 640 × 360)
Video Compression
Mainstream: H.265/H.264/H.264 /H.265

Sub-stream: H.265/H.264/MJPEG

Third stream: H.265/H.264
Video Bitrate 32 Kbps to 16 Mbps
H.264 Type Baseline Profile/Main Profile/High Profile
H.265 TypeMain Profile
Bitrate Control CBR/VBR
Scalable Video Coding (SVC)H.264 and H.265 encoding
Region Of Interest (ROI)1 fixed region for main stream and sub-stream

Audio
Audio Compression-U: G.711 ulaw/G.711 alaw/G.722.1/G.726/MP2L2/PCM/MP3/AAC
Audio Bit Rate-U: 64 Kbps (G.711 ulaw)/64 Kbps(G.711 alaw)/16 Kbps(G.722.1)/16 Kbps(G.726)/32 to 192 Kbps(MP2L2)/8 to 320 Kbps(MP3)/16 to 64Kbps(AAC)
Audio Sampling Rate-U: 8 kHz/16 kHz/32 kHz/44.1 kHz/48 kHz
Environment Noise Filtering-U: Yes

Network
Protocols TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, NTP, UPnP, SMTP, IGMP, 802.1X, QoS, IPv4, IPv6, UDP, Bonjour, SSL/TLS, PPPoE, SNMP
Simultaneous Live View Up to 6 channels
API Open Network Video Interface (Profile S, Profile G, Profile T), ISAPI, SDK
User/Host Up to 32 users. 3 user levels: administrator, operator and user
Security Password protection, complicated password, HTTPS encryption, IP address filter, Security Audit Log, basic and digest authentication for HTTP/HTTPS, TLS 1.1/1.2, WSSE and digest authentication for Open Network Video Interface
Network Storage NAS (NFS, SMB/CIFS), auto network replenishment (ANR)
ClientiVMS-4200, Hik-Connect, Hik-Central
Web Browser
Plug-in required live view: IE 10, IE 11

Plug-in free live view : Chrome 57.0 , Firefox 52.0

Local service: Chrome 57.0 , Firefox 52.0

Image Parameters Switch Yes
Image Settings Rotate, mirror, privacy mask, saturation, brightness, contrast, sharpness, gain, white balance adjustable by client software or web browser
Day/Night Switch Day, Night, Auto, Schedule
Wide Dynamic Range (WDR)130 dB
SNR≥ 52 dB
Image Enhancement BLC, HLC, 3D DNR

Interface
Ethernet Interface1 RJ45 10 M/100 M self-adaptive Ethernet port
On-Board Storage Built-in memory card slot, support microSD/microSDHC/microSDXC/TF card, up to 256 GB
Built-In Microphone-U: Yes
Reset Key Yes

Event
Basic Event Motion detection (human and vehicle targets classification), video tampering alarm, exception (network disconnected, IP address conflict, illegal login, HDD full, HDD error)
Smart Event
Line crossing, intrusion, region entrance, region exiting (support alarm triggering by specified target types (human and vehicle))

Scene change detection
Linkage Upload to FTP/memory card/NAS, notify surveillance center, trigger record, trigger capture, send email

Deep Learning Function
Face Capture Yes

General
Power
12V DC ± 25%, 0.5 A, max. 6 W, Ø5.5 mm coaxial power plug, reverse polarity protection

PoE: (802.3af, Class 3, 36 V to 57 V), 0.25 A to 0.15 A, max. 7.5 W
Dimension 78.8 × 78.6 × 215.2 mm (3.1" × 3.1" × 8.5")
Package Dimension 315 × 137 × 141 mm (12.4" × 5.4" × 5.6")
Weight Approx. 850 g (1.9 lb.)
With Package Weight Approx. 1270 g (2.8 lb.)
Storage Conditions-30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing)
Startup And Operating Conditions-30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing)
Language
33 languages

English, Russian, Estonian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Danish, Swedish, Norwegian, Finnish, Croatian, Slovenian, Serbian, Turkish, Korean, Traditional Chinese, Thai, Vietnamese, Japanese, Latvian, Lithuanian, Portuguese (Brazil), Ukrainian
General Function Anti-flicker, heartbeat, password reset via e-mail, pixel counter

Approval
EMC
FCC (47 CFR Part 15, Subpart B);

CE-EMC (EN 55032: 2015, EN 61000-3-2:2019, EN 61000-3-3:2013 A1:2019, EN 50130-4: 2011 A1: 2014);

RCM (AS/NZS CISPR 32: 2015);

IC (ICES-003: Issue 7)
Safety
UL (UL 62368-1);

CB (IEC 62368-1:2014 A11)

CE-LVD (EN 62368-1:2014/A11:2017)
Environment
CE-RoHS (2011/65/EU);

WEEE (2012/19/EU);

Reach (Regulation (EC) No 1907/2006)
Protection IP67 (IEC 60529-2013)
